SOURCE INPUT
☑ Input Channel
1

☑ Video
HDMI 1.4

☑ Video System
480i/p, 576i/p, 720p, 1080i/p

☑ Audio
HDMI

CONNECTIONS
☑ HDMI In
HDMI In

☑ HDMI Out
HDMI Pass Through

☑ RF Output
1 DVBT RF Output

☑ RF Input
RF Combiner

RF OUTPUT
☑ Type

☑ Frequency
177~858MHz

☑ MER
30dB Min

☑ Output Level
95 dBuV

☑ RF Level Adj
0dB~30dB

☑ Attenuation Step
1dB per step

POWER SUPPLY
☑ 12V 1A Adaptor

COMPRESSION
☑ Video
H.264 Baseline Profile Level 4.0

☑ Video Resolution
1080p 25 / 30 Max

☑ Video Bit Rate
12 Mbps Max

☑ Audio
MPEG-2/ AAC

☑ Audio Bit Rate
192 Kbit/s

☑ DVB Insertion Tables
SDT/ NIT

☑ Editable Field
Service Name, Network Name, Provider Name, TS ID, Network ID, Original NET ID, LCN, NIT Version, Private Data, Country

CONFIGURATION 6 LOCAL KEYS ON FRONT PANEL
☑ OK Key
Select Parameter, or Menu

☑ L /R Keys
Move menu, or Characters

☑ Up / Down
Select Value of the Figure, or Field

☑ Menu Keys
Select Menu

ENVIRONMENTAL FOR OPERATING
☑ Temperature
5°C – 40°C

☑ Relative Humidity
80% @ 30°C

MODULATION
☑ Standard
DVBT (ETSI EN 300 744)

☑ Constellation
QPSK, 16QAM, 64QAM

☑ Guard Interval
1/4, 1/8, 1/16, 1/32

☑ Code Rate
1/2, 2/3, 3/4, 5/6, 7/8

☑ FFT Carrier Mode
2K, 8K

☑ Bandwidth
6MHz, 7MHz, 8MHz, 7-8MHz

DISPLAY
☑ LCD Panel @ 2 x 16 Characters
