• For large installations of SAT IF distribution systems
• In line powering through H lines
• All components of 5 cable distribution system are compatible to each other
• Length of the subscriber line up to 80 meters
• Four positions discrete gain regulator for each SAT IF line and separate 16 positions discrete gain regulator for terrestrial TV
• Optimized for operation with terrestrial digital/analog signals
• Active terrestrial TV path powering from central power supply allows to receive terrestrial TV programs without switching on SAT TV receiver
• LED indication of 18 V line powering
• Possibility to feed LNBs and network equipment from external +18 V power supply unit recommended power supply -PS182F
• Die-cast housing

MV524

5×24 multiswitch

TECHNICAL SPECIFICATION

DECLARATION OF CONFORMITY

MANUAL
